API A-502 600W Pro Audio/Video Karaoke Mixing Amplifier

$ 399.99

Quantity

Product Details

The API A-502 Professional karaoke amplifier is one of the most advanced amplifier in the market today. This U.S. design amplifier pocess a 600 Watt output (peak) and is rack-mountable to any standard 19" rack with the optional rack-mountable kit.  It has all the necessary acoustic features sought by karaoke jockeys.The API A-502 Amplifier has many special features such as (4 video input)/(3 video output). This imply full-functions sources remote control of all four channels. It also feature independent mic & music tone control.

Đầu karaoke API A-502 Mixing Amplifier chuyên nghiệp là một trong những đầu Amplifier hiện đại và tiên tiến nhất trên thị trường hiện nay. Thiết kế đến từ Hoa Kỳ này đạt đến 600 Watt đầu ra (đỉnh). Đầu API A-502 Amplifier có nhiều tính năng đặc biệt như (đầu vào 4 video) / (3 đầu ra video) cùng với đầy đủ các chức năng điều khiển từ xa. API-A502 có thể điều khiển âm nhạc và mic độc lập

Features :

  • Stereo digital echo
  • Independent delay, repeat & echo control
  • 5 mic input (3-Front/2-Back)
  • High / Mid / Low microphone control
  • Microphone Stereo / Mono control
  • Independent mic & music tone control
  • Digital Key Control
  • Full function remote control : Source/Music-Mic Volume/Echo/Key/Mute/Vocal
  • 4 video input / 3 video output
  • Direct Access : Vocal Cancel/Vocal Partner/Digital Kay Control
  • Mid/Center/Rear speakers output
  • Cooling Fan
  • Rack kits included

Specifications :

  • Power: 300W x 300W (max)
  • Amplifier Output: (1KHz,-3db,6ohm): 0.03%
  • Total Harmonic Distortion:
    • Mic: 6mV/600ohm
    • Source: 300mV/22ohm
  • Input Sensitivity / Impedance:
    • PRE OUT: 2.5/1K ohm
    • REC OUT: 2.5/1K ohm
  • Output Level / Impedance:
    • MIC: 10Hz to 25kHz,+/-3dB
    • MUSIC: 10Hz to 40kHz,+/-3dB
  • Frequency Responses: MUSIC BASS: +/-10dB(100Hz)
  • Key Control Range: 9 steps +/-4 Tones
  • Video Input Sensitivity/Impedance: 1Vp-p/75ohm
  • Video Output Sensitivity/Impedance: 1p-p/75ohmz
  • Tone Control Characteristics:
    • MUSIC TREBLE: +/-10dB(10Hz)
    • MIC BASS: +/-10dB(100Hz)
    • MIC TREBLE: +/-10dB(10Hz)
    • 4 ohm to 16 ohm if use either terminal 1 or 2
  • Speaker Output Terminals: 6 ohm to 16 ohm use both terminal 1 and 2
  • Power Supply: 110-120V/220-240V,60/50Hz
  • Power Consumption: 450W
  • AC Power Outlets: Unswitched (200W max) x 2
  • Dimensions (W x D x H mm) 430x140x398mm
  • Weight: 33lbs
